IoT Data-acquisition Edge Gateway

Core Selling Tags

RK3568 industrial‑grade processor, optional NPU AI computing power, full‑range IO interfaces, Gigabit Ethernet ports + optical port expansion, multi‑mode communication adaptation, standard industrial‑protocol compatibility, full‑dimensional ODM/OEM customization

Product Overview

The industrial edge‑computing gateway is a high‑performance edge‑computing and data‑aggregation terminal built for industrial automation and smart IoT scenarios. The whole series is equipped with Rockchip RK3568 series industrial‑grade processors. Some models integrate NPU computing‑power units to undertake core functions including multi‑device data acquisition, multi‑protocol parsing & conversion, edge‑computing processing, and data forwarding & storage.

The device is equipped with abundant Ethernet ports, RS485/RS232 serial ports, DI/DO digital I/O, CAN bus and other IO resources. It supports multiple communication expansions such as WiFi, LoRa, 4G/5G. Natively compatible with mainstream industrial and IoT protocols including Modbus and MQTT, it seamlessly connects with various PLCs, industrial meters, sensor devices, third‑party monitoring platforms and data middle‑platforms. No proprietary backend platform binding is required, featuring flexible networking and strong adaptability.

The product series covers multiple form‑factors ranging from lightweight wall‑mounted type to 1U rack‑mounted type, with graded configurations for interfaces, computing‑power specifications and expansion capabilities. It meets edge‑deployment requirements for industrial production lines, power stations, municipal utility tunnels, smart parks, new‑energy stations and other scenarios. Adopting industrial‑grade hardware design, the unit runs stably for long periods under complex and harsh working conditions. Full‑dimensional ODM/OEM customization services are supported for the entire product line.

Core Product Advantages

1. Industrial‑grade Computing‑power Platform, Powerful Edge‑processing Performance
   The full series adopts RK3568‑family industrial‑grade quad‑core ARM Cortex‑A55 processors with maximum main frequency up to 2.0 GHz, delivering stable computing power and controllable power consumption. It handles concurrent multi‑device data collection, real‑time multi‑protocol parsing, edge pre‑processing and other tasks. Models Oak6040 / Oak6041 integrate a 512M NPU computing‑power unit to support edge‑AI inference, image recognition, intelligent analysis and other applications, satisfying edge‑computing requirements for intelligent scenarios.

2. Full‑range IO Interfaces for Access to Diverse Devices
   Rich industrial‑interface resources are provided, including Gigabit Ethernet, RS485/RS232 serial ports, DI/DO digital I/O, CAN bus and analog‑signal acquisition. It directly connects to on‑site equipment such as PLCs, industrial meters, sensors, industrial PCs and cameras without extra adapter modules. A single gateway realizes unified access and data aggregation for multi‑category devices.

3. Multi‑mode Communication Expansion for Flexible Networking & Integration
   Supports multiple communication methods: wired Gigabit Ethernet, SFP optical ports, WiFi, 4G, 5G and LoRa. Wired networking, wireless transmission, long‑range LoRa acquisition and other schemes can be selected according to on‑site network conditions. Redundancy designs including dual‑SIM card and electrical‑optical combo ports guarantee stable communication links, adapting to networking requirements for indoor computer rooms, outdoor stations, underground utility tunnels and other scenarios.

4. Industrial‑grade Reliable Design for Stable Operation under Complex Working Conditions
   Built with industrial‑grade components and metal housing, it supports wide‑voltage power supply and wide‑temperature operation, featuring strong anti‑electromagnetic‑interference, dust‑proof and moisture‑proof capabilities for harsh environments such as industrial workshops and power stations. Local large‑capacity storage expansion enables local data caching during network outages and automatic data resumption upon communication recovery to avoid monitoring‑data loss and ensure 7×24‑hour uninterrupted stable operation.

5. Full‑dimensional Customization to Meet Diversified Project Requirements
   Full‑range ODM/OEM services are available. Customizable options include hardware‑interface configurations, communication‑module adaptation, storage‑capacity upgrade, housing silk‑screen LOGO and neutral packaging. Custom firmware, private‑protocol adaptation & development and functional‑module tailoring are supported for seamless integration with third‑party industrial‑control systems and industry platforms. Both small‑batch and mass‑volume orders are acceptable to satisfy customized‑project demands across various industries and customers.


Communication & Integration Capabilities

This series of edge gateways are pure‑hardware edge‑computing terminals without binding to proprietary cloud platforms or mobile applications. Focused on data acquisition, protocol conversion, edge‑computing and standardized transmission, they meet third‑party‑system docking requirements for diverse projects.

• Industrial‑protocol Compatibility:
  Natively supports mainstream industrial protocols such as Modbus‑RTU and Modbus‑TCP. Directly connects to various PLCs, industrial meters and configuration software for seamless integration into existing industrial automatic‑control systems. Unified access and management for multi‑bus devices are supported.

• IoT‑platform Integration:
  Supports universal IoT protocols including MQTT. Data format, reporting cycle and encryption mode can be adjusted on‑demand for flexible connection to customer‑owned monitoring platforms, industry cloud platforms and data middle‑platforms. Private‑deployment docking is available.

• Edge‑data Processing:
  Enables local data cleaning, alarm‑logic judgment and cache‑and‑resume‑transmission upon network disconnection. NPU‑equipped models support edge‑AI inference to complete intelligent‑analysis tasks locally and reduce cloud‑computing‑power pressure and bandwidth consumption.

• Expandability:
  Private‑protocol adaptation, data‑forwarding rules, functional‑module tailoring and system‑firmware customization are available according to project requirements. Complete technical documents and docking support are provided for various customized‑project demands.


Application Scenarios

• Industrial Manufacturing: Production‑line device data acquisition, multi‑PLC networking communication, industrial‑data edge processing, factory digital‑transformation

• Power & Energy: Data aggregation, status monitoring and edge‑computing for equipment in substations, power‑distribution rooms, PV / wind‑power stations

• Municipal Utility Tunnels: Unified acquisition and edge forwarding for environmental, equipment and security‑system data in underground comprehensive utility tunnels

• Smart Parks: Aggregation and processing of park energy‑consumption, environmental and security‑device data, docking with park‑management platforms

• Intelligent Transportation: Data acquisition and edge‑processing for monitoring equipment in transportation stations, tunnels and road sections

• New‑energy Scenarios: Data acquisition, edge‑computing and cloud‑side docking for energy‑storage power stations and charging‑pile clusters
